AT04-3P-LE08 3 Position Receptacle Flange Mount Connector, Pin, Grey, with Strain Relief End Cap. DT04-3P-LE08

AT04-3P-LE08 3 Position Receptacle Flange Mount Connector, Pin, Grey, with Strain Relief End Cap. DT04-3P-LE08

IMAGE MAY DIFFER

AT04-3P-LE08

$0.00 AUD
$0.00 AUD
Sale Sold out

Downloads

Datasheet | 3D Model

Specifications

No. of Positions: 3
Gender: Male
Contact Size: 16
Colour: Grey
IP Rating: IP67 (in mated condition)
Insulation Resistance: 1000 megaohms min. @ 25°C
Operating Temperature: -55°C to +125°C
Mating Cycle Durability: >100
Housing Material: Thermoplastic
Seal Material: Silicone Rubber
Mating Part: AT06-3S* PLUG
Wedge Part: AW3P
Seal Diameter: 2.24mm (.088") - 3.68mm (.145")
Shape: Rectangular

3 Position Receptacle Flange Mount Connector, Pin, Grey, with Strain Relief End Cap
