AT04-3P-PM05 3-Way Flange Mount Receptacle with Gasket

Name: AT04-3P-PM05 3-Way Flange Mount Receptacle with Gasket
Brand: Amphenol Sine Systems
SKU: AT04-3P-PM05
Availability: InStock

IMAGE MAY DIFFER

SKU:AT04-3P-PM05

$0.00 AUD

Sale Sold out

Quantity

Downloads

Datasheet | 3D Model

Specifications

No. of Positions: 3
Gender: Male
Contact Size: 16
Colour: Grey
IP Rating: IP67 (in mated condition)
Insulation Resistance: 1000 megohms at 25°C
Operating Temperature: -55°C to +125°C
Mating Cycle Durability: >100
Housing Material: Thermoplastic
Seal Material: Silicone Rubber
Mating Part: AT06-3S* Plug
Wedge Part: AW3P
Seal Diameter: 2.24mm (.088") - 3.68mm (.145")
Wire Range: 14-20 AWG
Shape: Triangular

3-Way Flange Mount Receptacle with Gasket
