C016 10H006 000 10 6+PE Male, straight cable connector with strain relief and clamping ring. Crimp contacts sold separately. Available in gold or silver plating.
C016 10H006 000 10 6+PE Male, straight cable connector with strain relief and clamping ring. Crimp contacts sold separately. Available in gold or silver plating.
IMAGE MAY DIFFER
SKU:
Regular price
$0.00 AUD
Regular price
Sale price
$0.00 AUD
Unit price
/
per
Couldn't load pickup availability
Stock Level
Stock levels vary — Contact us for detailsDownloads
Datasheet3D Model
Specifications
Style: Straight
Gender: Male
Current Carrying Capacity: 13A
Contact Size: 1.6mm
Contact Quantity: 7
Colour: Blue
IP Rating: IP65/67
Contact Plating: Silver or Gold
Insulation Resistance: ≥ 10(8) Ω
Operating Temperature: -40°C to +125°C
Housing Material: PA 6.6 / PA6
Wire Range: 0.14 - 1.5mm² (26-16 AWG)
Shape: circular
6+PE Male, straight cable connector with strain relief and clamping ring. Crimp contacts sold separately. Available in gold or silver plating.
