C016 20K003 100 10 3+PE Male, right angled cable connector with strain relief and clamping ring. Field installable screw termination.. Comparable part no: 99-4221-70-04, CA3WLS
C016 20K003 100 10 3+PE Male, right angled cable connector with strain relief and clamping ring. Field installable screw termination.. Comparable part no: 99-4221-70-04, CA3WLS
IMAGE MAY DIFFER
SKU:
Regular price
$0.00 AUD
Regular price
Sale price
$0.00 AUD
Unit price
/
per
Couldn't load pickup availability
Stock Level
Stock levels vary — Contact us for detailsDownloads
Datasheet3D Model
Specifications
Style: Right angle
Gender: Male
Current Carrying Capacity: 16A
Contact Quantity: 4
Colour: Blue
IP Rating: IP65/67
Contact Plating: Silver
Insulation Resistance: ≥ 10(8) Ω
Operating Temperature: -40°C to +100°C
Housing Material: PA 6.6 / PA6
Mating Part: C01620D00310010,C01620D00310012,C01620D00311010,C01620D00311012,C01620D00320010,C01620D00320012,C01620D00321010,C01620D00321012,C01620F00310010,C01620F00310012,C01620F00320012,C01620G00310012
Wire Range: 0.75 - 2.5mm² (18-14 AWG)
Shape: circular
3+PE Male, right angled cable connector with strain relief and clamping ring. Field installable screw termination.
