C091 31G107 100 2 Rear mounting female metal Connectors with O-ring seal and ring nut mount (hex nut available upon request). Complete EMI shielding in the fully mated and locked position (EMI security). Contacts included. DIN EN 610
C091 31G107 100 2 Rear mounting female metal Connectors with O-ring seal and ring nut mount (hex nut available upon request). Complete EMI shielding in the fully mated and locked position (EMI security). Contacts included. DIN EN 610
IMAGE MAY DIFFER
SKU:C09131G1071002
Regular price
$0.00 AUD
Regular price
Sale price
$0.00 AUD
Unit price
/
per
Couldn't load pickup availability
Downloads
DatasheetSpecifications
Contacts: 7 B Arrangement
Current Rating: 7A
IP Rating: IP67/ 65 (in mated condition)
Contact Plating: Silver
Termination: Solder
Insulation Resistance: ≥ 10(10) Ω
Operating Temperature: -40°C to +100°C
Housing Material: Die cast, nickel plated
Mating Part: C09131H0071004,C09131H0071014,C09131H0071024,C09131H1071004,C09131H1071014,C09131H1071024
Shape: circular
Rear mounting female metal Connectors with O-ring seal and ring nut mount (hex nut available upon request). Complete EMI shielding in the fully mated and locked position (EMI security). Contacts included. DIN EN 610
