C091 61N014 210 2 Front mounting female metal Connectors with O-ring seal and ring nut mount (hex nut available upon request). Complete EMI shielding in the fully mated and locked position (EMI security). Contacts included
C091 61N014 210 2 Front mounting female metal Connectors with O-ring seal and ring nut mount (hex nut available upon request). Complete EMI shielding in the fully mated and locked position (EMI security). Contacts included
IMAGE MAY DIFFER
SKU:C09161N0142102
Regular price
$0.00 AUD
Regular price
Sale price
$0.00 AUD
Unit price
/
per
Couldn't load pickup availability
Downloads
DatasheetSpecifications
Contacts: 14
Current Rating: 3A
IP Rating: IP67/ 65 (in mated condition)
Contact Plating: Gold
Termination: Solder
Insulation Resistance: ≥ 10(10) Ω
Operating Temperature: -40°C to +100°C
Housing Material: Die cast, nickel plated
Mating Part: C091 31W014 200 2, C091 31C014 200 2, C091 31S014 200 2, C091 31H014 200 2
Shape: circular
Front mounting female metal Connectors with O-ring seal and ring nut mount (hex nut available upon request). Complete EMI shielding in the fully mated and locked position (EMI security). Contacts included
