T 3526 518 Straight, full plastic front mounting male Connectors with snap-in mount. 1.5mm max panel thickness (±0.25). Bayonet locking outside (mateable with locking inside). Contacts included.

T 3526 518 Straight, full plastic front mounting male Connectors with snap-in mount. 1.5mm max panel thickness (±0.25). Bayonet locking outside (mateable with locking inside). Contacts included.

IMAGE MAY DIFFER

SKU:T3526518

Downloads

Datasheet

Specifications


Contacts: 8
Current Rating: 7A
IP Rating: IP40
Contact Plating: Gold
Termination: Solder
Insulation Resistance: ≥ 10(10)  Ω
Operating Temperature: -40°C to +100°C
Housing Material: Die cast, nickel plated
Mating Part: T 3525 518, T 3525 528, T 3525 548, T 3525 058
Shape: circular

Straight, full plastic front mounting male Connectors with snap-in mount. 1.5mm max panel thickness (±0.25). Bayonet locking outside (mateable with locking inside). Contacts included.
