T 3652 404 Rear mounting male Connectors with ring nut (hex nut available upon request). Pin length of 10.5mm from flange. Contacts included.
T 3652 404 Rear mounting male Connectors with ring nut (hex nut available upon request). Pin length of 10.5mm from flange. Contacts included.
IMAGE MAY DIFFER
SKU:T3652404
Couldn't load pickup availability
Downloads
DatasheetSpecifications
Contacts: 14
Current Rating: 3A
IP Rating: IP40
Contact Plating: Gold
Termination: Solder
Insulation Resistance: ≥ 10(10) Ω
Operating Temperature: -40°C to +100°C
Housing Material: Die cast, nickel plated
Mating Part: T3651000,T3651002,T3651004
Shape: circular
Rear mounting male Connectors with ring nut (hex nut available upon request). Pin length of 10.5mm from flange. Contacts included.
