T 3653 304 Front mounting female Connectors with ring nut (hex nut available upon request). Pin length of 15mm from flange. Solder area is tin plated, sealing with O-ring. Contacts included.
T 3653 304 Front mounting female Connectors with ring nut (hex nut available upon request). Pin length of 15mm from flange. Solder area is tin plated, sealing with O-ring. Contacts included.
IMAGE MAY DIFFER
SKU:T3653304
Regular price
$0.00 AUD
Regular price
Sale price
$0.00 AUD
Unit price
/
per
Couldn't load pickup availability
Downloads
DatasheetSpecifications
Contacts: 14
Current Rating: 3A
IP Rating: IP40
Contact Plating: Gold
Termination: Solder
Insulation Resistance: ≥ 10(10) Ω
Operating Temperature: -40°C to +100°C
Housing Material: Die cast, nickel plated
Mating Part: T3650000,T3650002,T3650004,T3650058
Shape: circular
Front mounting female Connectors with ring nut (hex nut available upon request). Pin length of 15mm from flange. Solder area is tin plated, sealing with O-ring. Contacts included.
